The No. 1 for building projects with the highest fire protection requirements: ALUCOPANEL® A1 is non-combustible and also no smoke development in case of fire. A sustainable alternative to façade materials made of metal or other cladding.

Key Benefits
  • Reaction to Fire Classification (Class A1)
  • Extremely durable
  • Resistant to extreme weather
  • Wide Range of Colours
  • Different surface finishes
  • Lightweight and rigid
  • Low cost fabrication
  • Up to 20 years warranty
  • Certified and Tested
Expand



Full Details

ALUCOPANEL® A1 is a composite panel consisting of two 0.5 mm thick aluminium cover sheets and a non-combustible mineral core (3 mm). The core consists of 100% non-combustible ingredients. ALUCOPANEL® A1 is currently the only composite panel in the Middle East region that is classified for the highest fire protection class A1 according to EN 13501-1. This means: non-combustible and also no smoke development in case of fire. A sustainable alternative to façade materials made of metal or other cladding. Like all ALUCOPANEL® products, ALUCOPANEL® A1 is easy to process and shape, weather resistant, impact resistant and has a high degree of flatness. The front side is colour-coated with the high-quality Polyvinylidene fluoride (PVDF), making it highly resistant to weathering, UV radiation, corrosion and colour fading.

For further information, you can access the product brochures and technical documents below.

View Brochures
Applications

ALUCOPANEL® A1 is suitable for a huge range of applications in a variety of industries.

Façade / Cladding
  • Super High-rise buildings
  • High-rise buildings
  • Malls
  • Theme Parks
  • Schools
  • Hospitals
Technical

Here are the sheets sizes and thicknesses available as standard along with the technical specification of ALUCOPANEL® A1.

TEST STANDARD TOLERANCE RESULT
4MM
Panel Thickness Calibrated Caliper (±) 0.2 mm 4 mm
Weight of the Panel Calibrated weighing device ± 0.5 kg/m2 8.0kg/m2
Standard Width ... (±) 2 mm 1000, 1250, 1500, up to 2000 mm
Length ... (±) 2 mm up to 6000 mm
Max. 8000 mm
Skin Thickness Caliper 0.5 (±) 0.02 mm 0.50 mm
TEST STANDARD REQUIREMENT RESULT / CERTIFICATE REF. NO.
4MM
Reaction to Fire EN 13501-1 Class A1 TBW 0300647
Self and Flash Ignition
Temperature (CORE)		 ASTM D 1929 Not less than 343°̊C SIT: > 750°C,
FIT: > 750°C
Self and Flash Ignition
Temperature (ACP)		 ASTM D 1929 Not less than 343 ̊C SIT: > 525°C,
FIT: > 524°C
Exterior Wall Cladding System NFPA 285 Pass as per standard TBW 0300672
Roof Covering Assembly
with Mineral Wool Insulation
(45-70˚ from the horizontal plane)		 EN 13501-5 BROOF(t4) TBW0300736
With thermal insulation
fixed direct at rear face of
ACP, on Alum structure with
300 mm Void ideal for
Continuous Roof Covering.
Roof pitch: 10˚ to 70˚
Roof Covering Assembly
(10-70˚ from the horizontal plane)		 EN 13501-5 BROOF(t4) TBW0300737
without any packing
material on Alum structure
with 300mm Void ideal for
canopies and feature.
Roof pitch: 10˚ to 70˚
TEST STANDARD REQUIREMENT RESULT
4MM
Alloy / Temper ASTM B209 3105 - H16
Tensile Strength ASTM E8 172 - 221 N/mm2 196 N/mm2
Yield Strength ASTM E8 Min. 145 N/mm2 190 N/mm2
Elongation ASTM E8 Min. 1.0% 4.2%
Modulus of Elasticity ASTM E111 Measure Value 69 Gpa
TEST STANDARD REQUIREMENT RESULT
4MM
Peel off Strength ASTM D 903 ≥ 10 kg/25mm 17.35 kg/25 mm
Shear Strength ASTM D 273 ≥ 3.2 MPa 3.35 MPa
Tensile Strength ASTM E8 ≥ 35 MPa for 4mm 44.48 Mpa
Punch Shear Test ASTM D 732 ≥ 20 MPa 23.77 Mpa
TEST STANDARD REQUIREMENT RESULT
4MM
Temperature for Thermal deformation ASTM D 648 ≥ 100˚C 149˚C
Linear Thermal Expansion per 100˚C ASTM D 696 ≥ 2.4 mm/m/c° ≥ 2.4 mm/m/c°
Thermal Conductivity ASTM C 518 Measure Value 0.129 W/mK
TEST STANDARD REQUIREMENT RESULT
4MM
Type / Finish PVDF / FEVE / HDPE PVDF / FEVE / HDPE
Coating Thickness ASTM D 1400 ≥ 25μm ≥ 25μm
Weathering Resistance ASTM C 481 A. Shear Strength
B. Film Adhesion
C. Impact Resistance 		A. 3.75 Mpa (after exposure)
B.1.Dry Adhesion - No removal of film
B.2. Wet Adhesion - No removal of film
B.3. Boiling Water - No removal of film
C. Impact Resistance - No removal of film
Corrosion Resistance
(Humidity Resistance & Salt Spray)		 AAMA 2605 A. Humidity Resistance
(@4000 hours exposure)
B. Salt Spray Resistance
(@4000 hours, 35˚C) 		A. No formation of blisters
B.1 Scribed - rating of 9
B.2. Unscribed - rating of 10
Chemical Resistance ISO 2812 -1: 2014 A. Acid Resistance
B. Alkali Resistance
C. Oil Resistance
D. Solvent Resistance		 A. NO CHANGE
B. NO CHANGE
C. NO CHANGE
D. NO CHANGE
Abrasion Resistance ASTM D 968 ≥ 50 L/mil 55.5 L/mil
T-Bend Test ASTM D 522 2T (No Cracks) 2T (No Cracks)
Pencil Hardness ASTM D 3363 ≥ H ≥ H
Film Adhesion
DRY (@27 ˚C)
WET (@38 ˚C, 24hrs)
BOILING (@100 ˚C, 20hrs)		 AAMA 2605
(Clause 7.4)		 No removal of film No removal of film
of the cross- hatched area;
No blistering was observed
Impact Resistance Test 50 kg-cm AAMA 2605
(Clause 7.5)		 No removal of film No removal of film
REMARK: Coating Performance results are complying with AAMA 2605-13 Requirements
Colours

In addition to our stock range, ALUCOPANEL® A1 can also be colour matched to almost any RAL colour - allowing corporate colours to be matched with ease.

APL - S22 APL - S30 APL - S19 APL - S25 APL - S27 APL - S26 APL - S28 APL - S29 APL - S5712 APL - S5239 APL - S5724 APL - S18 APL - S20 APL - S1265 APL - S5054 APL - S0339 APL - S3076 APL - S40 APL - S42 APL - S41 APL - S24 APL - S17 APL - S37 APL - S81

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - M10 APL - M33 APL - M01 APL - M02 APL - M07 APL - M21 APL - M5576 APL - M04 APL - M03 APL - M4434 APL - M2218 APL - M6234 APL - M7730 APL - M09 APL - M5604 APL - M4367 APL - M0536 APL - M06 APL - M08 APL - M12 APL - M13 APL - M43

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - M70 APL - M264/265 APL - MS123 APL - M027 APL - M245 APL - M749

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - S2065 APL - S2960 APL - S2083 APL - S2066 APL - S2068 APL - S2204

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - SS01

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - W23 APL - W44 APL - W45 APL - W61 APL - W60

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us

Bright Silver
