Architectural



Light weight composite material ideal for signages and facades. Limited non-combustibility, it can protect buildings and properties from fire. Varied selection of colors and finishes perfect for aesthetics and architecture.

Key Benefits
  • Reaction to fire classification B-s1, d0 (EN 13501-1)
  • Extremely durable
  • Resistant to extreme weather
  • Wide Range of Colours
  • Different surface finishes
  • Lightweight and rigid
  • Low cost fabrication
  • Up to 20 years warranty
  • Certified and Tested
Expand
Full Details

ALUCOPANEL® FR is composed of two sheets of High Grade 3105 aluminum alloy H16 temper with 0.50 mm thickness on Top (Coated with high quality PVDF paint comes in various finishes such as Solid Colors & Metallic colors) & bottom (primer coated) that is sandwiched with mineral filled / flame retardant core material, thus

ALUCOPANEL® FR achieved limited combustible reaction to fire classification “Class B -s1, d0” when tested in accordance to European Standard EN 13501-1, this product is suitable for 23-meter below building as low-rise, Mid-rise, Industrials, Warehouse and for a non-crowded structures as mandatory requirement in U.A.E as per Latest Edition of U.A.E Fire & Life Safety Guidelines.

For further information, you can access the product brochures and technical documents below.

View Brochures
Applications

ALUCOPANEL® FR is suitable for a huge range of applications in a variety of industries including those where fabrication is required.

Façade / Cladding
  • Warehouse
Technical

Here are the sheets sizes and thicknesses available as standard along with the technical specification of ALUCOPANEL® FR.

TEST STANDARD TOLERANCE RESULT
4MM 6MM
Panel Thickness Screw Gauge/Vernier caliper (±) 0.2 mm 4 mm 6 mm
Weight of the Panel Weighing scale ± 0.5 kg/m2 8.2 kg/m2 11.7 kg/m2
Standard Width Measuring tape (±) 2 mm 1000, 1250, 1500
Length Measuring tape (±) 2 mm up to 6000 mm
Max. 8000 mm
Skin Thickness Screw Gauge/Vernier caliper (±) 0.02 mm 0.5 mm
TEST STANDARD REQUIREMENT RESULT / CERTIFICATE REF. NO.
4MM 6MM
Reaction to Fire EN 13501-1 Class B, s1, d0 TBW 0300136
Surface Burning
Characteristics 		ASTM E84 (FSI) 25-0
(SDI) 450-0 		FSI 15, SDI 30
Class A		 FSI 15, SDI 40
Class A
Self Ignition
Temperature (ACP)		 ASTM D 1929 Not less than 343˚C SIT (783˚F) 417˚C,
FIT (779˚F) 415˚C 		SIT (849˚F) 454˚C,
FIT (846˚F) 452˚C
Self Ignition
Temperature (CORE)		 SIT (777˚F) 414˚C,
FIT (763˚F) 406˚C		 SIT (777˚F) 414˚C,
FIT (763˚F) 406˚C
Exterior Non-Load Bearing
Wall Cladding Assemblies 		NFPA 285 As per standard TBW0300169 TBW0300118
Roof Covering Assembly
(0-10˚ from the horizontal plane) 		EN 13501-5 BROOF(t4) TBW0300740
without any packing
material on Alum structure
with 300mm Void ideal for
canopies and feature.		 -
TEST STANDARD REQUIREMENT RESULT
4MM 6MM
Alloy / Temper ASTM B209 3105 - H16
Tensile Strength ASTM E8 172 - 221 N/mm2 196 N/mm2
Yield Strength Min. 145 N/mm2 190 N/mm2
Elongation Min. 1.0% 4.2%
Modulus of Elasticity ASTM E111 Measure Value 69 Gpa
TEST STANDARD REQUIREMENT RESULT
4MM 6MM
Peel off strength @ 180° ASTM D 903 ≥ 10 kg/25mm 17.57 kg/25mm 15.6 kg/25mm
Climbing Drum Peel ASTM D1781 Measure Value 17.3 kg/25mm 17.3 kg/25mm
Shear Strength ASTM C 273 ≥ 3.2MPa 3.25 Mpa 3.23 Mpa
Tensile strength ASTM E8 ≥ 35MPa for 4mm
≥ 25MPa for 6mm		 42.83 MPa 29.63 MPa
0.2% Proof Stress ASTM E8 Measure Value 47.0 MPa 34.0 MPa
Punch Shear Test ASTM D 732 ≥ 20 MPa 22.29 MPa 21.93 MPa
Modulus of Elasticity ASTM C393 Measure Value 19,600 Mpa
Flexural Strength ASTM D790-17 Measure Value 110.7 Mpa
TEST STANDARD REQUIREMENT RESULT
4MM 6MM
Deflection Temperature ASTM D 648 ≥ 100˚C ≥ 250˚C
Linear Thermal Expansion per 100˚C ASTM D 696 ≥ 2.4 mm/m/ ˚C 2.4 mm/m/ ˚C 2.6 mm/m/ ˚C
Thermal Conductivity ASTM C 518 Measure Value 0.12 W/mK 0.23 W/mK
TEST STANDARD REQUIREMENT RESULT
4MM 6MM
Type / Finish PVDF / FEVE / HDPE PVDF / FEVE / HDPE
Coating Thickness ASTM D 1400 ≥ 25μm ≥ 25μm
Weathering Resistance ASTM C 481 A. Shear Strength
B. Film Adhesion
C. Impact Resistance 		A. 3.75 Mpa (after exposure)
B.1.Dry Adhesion - No removal of film
B.2. Wet Adhesion - No removal of film
B.3. Boiling Water - No removal of film
C. Impact Resistance - No removal of film
Corrosion Resistance
(Humidity Resistance & Salt Spray)		 AAMA 2605 A. Humidity Resistance
(@4000 hours exposure)
B. Salt Spray Resistance
(@4000 hours, 35˚C) 		A. No formation of blisters
B.1 Scribed - rating of 9
B.2. Unscribed - rating of 10
Chemical Resistance ISO 2812 -1: 2014 A. Acid Resistance
B. Alkali Resistance
C. Oil Resistance
D. Solvent Resistance 		A. NO CHANGE
B. NO CHANGE
C. NO CHANGE
D. NO CHANGE
Abrasion Resistance ASTM D 968 ≥ 50 L/mil 52.7 L/ mil
T-Bend Test ASTM D 522 2T (No Cracks) 2T (No Cracks)
Pencil Hardness ASTM D 3363 ≥ H ≥ H
Film Adhesion
DRY (@27 ˚C)
WET (@38 ˚C, 24hrs)
BOILING (@100 ˚C, 20hrs)		 AAMA 2605
(Clause 7.4)		 No removal of film No removal of film
of the cross- hatched area;
No blistering was observed
Impact Resistance Test 50 kg-cm AAMA 2605
(Clause 7.5)		 No removal of film No removal of film
REMARK: Coating Performance results are complying with AAMA 2605-13 Requirements
Colours

In addition to our stock range, ALUCOPANEL® FR. can also be colour matched to almost any RAL colour - allowing corporate colours to be matched with ease.

APL - S22 APL - S30 APL - S19 APL - S25 APL - S27 APL - S26 APL - S28 APL - S29 APL - S5712 APL - S5239 APL - S5724 APL - S18 APL - S20 APL - S1265 APL - S5054 APL - S0339 APL - S3076 APL - S40 APL - S42 APL - S41 APL - S24 APL - S17 APL - S37 APL - S81

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - M10 APL - M33 APL - M01 APL - M02 APL - M07 APL - M21 APL - M5576 APL - M04 APL - M03 APL - M4434 APL - M2218 APL - M6234 APL - M7730 APL - M09 APL - M5604 APL - M4367 APL - M0536 APL - M06 APL - M08 APL - M12 APL - M13 APL - M43

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - M70 APL - M264/265 APL - MS123 APL - M027 APL - M245 APL - M749

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - S2065 APL - S2960 APL - S2083 APL - S2066 APL - S2068 APL - S2204

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - SS01

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us
APL - W23 APL - W44 APL - W45 APL - W61 APL - W60

1) Above color samples displayed are for reference only, before ordering please double check the color of actual material.

2) To avoid possible reflection differences, it is imperative to install the panels in the same direction as marked on the protective film.

3) Please order the total requirements for one particular building in a single order, for metallic and solid colors, an optical change of color shade may occur due to the metallic particles of these lacquers.

4) Tolerance in color between batches: ∆E2.0 in accordance to ISO 7724-3 (EN 1396:1996)

Contact Us

Bright Silver
